Toshiba has made available TB9032FNG, the first product of an automotive driver/receiver IC for the physical-layer interfaces defined in the Clock Extension Peripheral Interface (CXPI), the standard for automotive communications protocols. This new product facilitates CXPI communication by combining it with an MCU that has a built-in CXPI controller.
The electrification of automobiles is increasing the number of electronic components in automotive systems, adding to their complexity and vehicle weight, as more wiring harnesses are required. As a solution to this issue, CXPI, which can reduce wire harnesses through multiplex transmission in-vehicle communication technology, is attracting attention as a communication standard suitable for sub-networks in automotive body applications, combining low cost and high responsiveness.
.
Key Features and Benefits:
- Optimized Power Efficiency: Reduces power consumption, extending battery life in electric vehicles.
- Advanced Safety Mechanisms: Supports critical safety functions like collision avoidance and lane-keeping assistance.
- Robust Reliability: Withstands extreme temperatures and harsh environments, meeting AEC-Q100 standards.
- Versatile Integration: Easily integrates into various automotive applications, from compact cars to heavy-duty vehicles.
- High Durability: Built to endure extreme conditions, ensuring long-lasting performance.
"Our new semiconductor represents a major leap forward in vehicle technology, providing manufacturers with the tools they need to create safer, more efficient, and more reliable vehicles." Executive officer at Toshiba
Product Details:
- Physical Layer Interface: Conforms to CXPI, the standard for automotive communications protocols.
- High-Speed Response: Suitable for automotive body applications such as steering switches and light switches.
- Node Selection: Switchable between commander node and responder node via an external terminal.
- Fault Detection Functions: Includes overheat detection, low-voltage detection, dominant time-out, and overcurrent limitation.
- Low Consumption Current: Features a sleep mode with typical consumption current (IBAT_SLP) of 5μA.
- Package: Standard SOP8 package (6.0×4.9mm) for efficient mounting in limited space.
- Reliability: Designed to conform to AEC-Q100 (Grade 1) qualification standards
Applications
Automotive equipment
- Body control system applications (Steering switches, meter cluster switches, light switches, door locks, controlled door mirrors, etc.)
- Zone ECU interface
The launch of this new semiconductor underscores Toshiba's dedication to advancing automotive technology and supporting the global transition to sustainable transportation solutions.
