New 9-megapixel global shutter image sensor for industrial machine vision

OMNIVISION unveiled its new OG09A10 CMOS global shutter (GS) sensor – the company’s first large-format GS solution for factory automation and intelligent transportation systems (ITS). The large-pixel, 3.45 µm backside-illuminated (BSI) stacked global shutter sensor, with its low readout noise and the highest quantum efficiency (QE) in its class, delivers excellent image quality, making it ideal for machine vision applications that require the ability to capture clear images of high-speed moving objects. 1-inch Color CMOS 9‑Megapixel (4096 x 2160) Image Sensor with PureCelPlus‑S, Global Shutter, and Nyxel Technologies for Machine Vision Applications
The OG09A10 is a 9-megapixel (MP) GS sensor with a 1-inch optical format. The sensor’s 3.45 µm pixel is based on OMNIVISION’s patented PureCelPlus-S stacked-die architecture for best-in-class image sensor performance. The OG09A features Nyxel near-infrared (NIR) technology for crisp, clear images in low-light conditions. Dual Conversion Gain High Dynamic Range (DCG HDR) technology further extends the GS image sensor’s dynamic range capabilities and reproduces artifact–free, low-noise images in challenging lighting conditions. “Charge-coupled device (CCD) image sensors are being replaced with CMOS image sensors, resulting in volume growth of t...
